Light on the right side
The horizontal shelf lighting generates optimal that the products are evenly lit, right to the back of the display.
Installation Size
The RFM-H can be screwed fast and easy directly to the shelf via the end caps or the RFM clip. It is also possible to install the lighting bar via magnet (on end caps or RFM clip). Adhesive strips are not recommended.
RFM-H Series
|
Article description
|
Article no.
|
Length
|
Colour temperature
|
Luminous flux
|
Power
|
CRI
|
|
RFM-H L600
|
RFM0600H30A
|
600 mm
|
3.000 K / ww
|
460 lm
|
5,7 W
|
> 80
|
|
RFM-H L600
|
RFM0600H40A
|
600 mm
|
4.000 K / nw
|
480 lm
|
5,7 W
|
> 80
|
|
RFM-H L600
|
RFM0600H65A
|
600 mm
|
6.500 K / cw
|
480 lm
|
5,7 W
|
> 80
|
|
RFM-H L600
|
RFM0600HFRA
|
600 mm
|
Fresh meat
|
390 lm
|
5,7 W
|
> 80
|
|
RFM-H L900
|
RFM0900H30A
|
900 mm
|
3.000 K / ww
|
690 lm
|
8,7 W
|
> 80
|
|
RFM-H L900
|
RFM0900H40A
|
900 mm
|
4.000 K / nw
|
720 lm
|
8,7 W
|
> 80
|
|
RFM-H L900
|
RFM0900H65A
|
900 mm
|
6.500 K / cw
|
720 lm
|
8,7 W
|
> 80
|
|
RFM-H L900
|
RFM0900HFRA
|
900 mm
|
Fresh meat
|
610 lm
|
8,7 W
|
> 80
|
|
RFM-H L1200
|
RFM1200H30A
|
1.200 mm
|
3.000 K / ww
|
920 lm
|
11,5 W
|
> 80
|
|
RFM-H L1200
|
RFM1200H40A
|
1.200 mm
|
4.000 K / nw
|
965 lm
|
11,5 W
|
> 80
|
|
RFM-H L1200
|
RFM1200H65A
|
1.200 mm
|
6.500 K / cw
|
965 lm
|
11,5 W
|
> 80
|
|
RFM-H L1200
|
RFM1200HFRA
|
1.200 mm
|
Fresh meat
|
805 lm
|
11,5 W
|
> 80
|
|
RFM-H L1500
|
RFM1500H30A
|
1.500 mm
|
3.000 K / ww
|
1.150 lm
|
16 W
|
> 80
|
|
RFM-H L1500
|
RFM1500H40A
|
1.500 mm
|
4.000 K / nw
|
1.210 lm
|
16 W
|
> 80
|
|
RFM-H L1500
|
RFM1500H65A
|
1.500 mm
|
6.500 K / cw
|
1.210 lm
|
16 W
|
> 80
|
|
RFM-H L1500
|
RFM1500HFRA
|
1.500 mm
|
Fresh meat
|
1.015 lm
|
16 W
|
> 80
|
